Material
Urethane Casting
Plastics (ABS, Acryl)
Urethane Rubber (More than 45A)
PP (Black)
Injection Molding
General resin : PC, PC+ABS, ABS, PE, PP, PS, PET, POM, PA6, PA66, etc
Reinforced resin : GF%+, CF%+, PEEK, PPSU, etc
Clear resin : PC, PMMA, ABS, etc
Soft resin : TPU, TPE, TPS
Size : Part Max 350×450×200 (Core Max 640×520×280)
The available size will be confirmed by undercut existence.
Colors : Basically there are lots of color in resin and color matching is available as well.
Quick Turn (Mobile phone size)
Simple : 7 days, Medium : 10 days, Complex : 13 days
Tool Material
Core/Cavity : Al(dr79), P20, KP4M, Nak80 or negotiable
Slider, Insert : Al(dr79), P20, KP4M, Nak80 or negotiable
Ejector, Lifter : SKD 61
Key Quality Criterions
Sink, Color match, Flow mark, Scratch, etc
